Product Details:
|
| Model Name: | Flame-fused Optical Fiber Coupler | Optical Coupler Configuration Type: 1x2 Operating Wavelength: | 1310nm,1490nm,1550 Nm |
|---|---|---|---|
| Split Ratio: | 50/50,40/60,30/70,20/80,10/90,5/95 Etc | Other Types: | Singlewindow, Dualwindow,Triplewindow |
| Function: | Fiber Distribution | Available Pre-terminated: | LC/UPC, LC/APC, SC/UPC, SC/APC, FC/UPC, FC/APC, And ST/UPC |
| Polarization Alignment: | Slow Axis Or Fast Axis | Fiber Type: | PM Fiber Cable 62.5/125um |
| Package Type: | Steel Tube | Configuration Type: | 3×5 |
| Highlight: | 10/90 Fiber Optic Cable Coupler,10/90 fused fiber coupler,1490nm optical fiber coupler |
||
Low PDL Flame-fused Optical Fiber Directional Couplers For CATV System
Optic Coupler Brief Introduces:
Fiber Optic FBT splitter is a type of optical power management device that is fabricated using Fused technology, which features small size, high reliability, cheap cost, and good channel-to-channel uniformity and is widely used in PON networks to realize optical signal power splitting.
As the Top manufactures of fiber optic couplers, Geehe's equipment, and Test equipment are all imported from Japan, more precision, the workers with 15 years experience, the products are high stability and reliability.
Fiber Optic Coupler Features& Benefits:
Wide Brand Coupler Specification and parameter:
| Parameter | P | A | |||
| Operating Wavelength(nm) | 1310&1550 | ||||
| Operating Bandwidth(nm) | 1310 ± 40nm,1550 ± 40nm | ||||
| Fiber Type(dB) | Corning G652D OR Corning G657 A1 | ||||
| Insertion Loss (dB) |
50/50 | ≤3.3 | ≤3.5 | ||
| 40/60 | 3.70~4.40≤2.5 | 3.50~4.60/≤2.8 | |||
| 30/70 | 5.00~5.60/≤1.8 | 4.90~6.10/≤2.1 | |||
| 20/80 | 6.80~7.40/≤1.2 | 6.50~7.70/≤1.2 | |||
| 10/90 | 9.60~10.50/≤0.6 | 8.80~11.40/≤0.8 | |||
| 5/95 | 12.70~13.50 /≤0.4 | 12.05~14.05/≤0.5 | |||
| 3/97 | 14.60~15.50/≤0.3 | 13.60~16.05/≤0.4 | |||
| 2/98 | 16.60~17.90/≤0.25 | 15.60~18.20/≤0.3 | |||
| 1/99 | 19.20~20.80/≤0.2 | 18.80~21.40/≤0.25 | |||
| PDL(dB) | ≤0.1 | ≤0.15 | |||
| Return Loss(dB) | ≥55 | ≥45 | |||
| Directivity(dB) | ≥55 | ||||
| Operating Temperature(℃) | -40 ~ +85 | ||||
* The above specification is without connector
* Other specifications can be made on customer request
Ordering Information:
| WBC- | X- | X2- | 35- | XX- | X- | XX- | XX- | X |
| P: Premium A: Grade A X: Customization |
12:1x2 22:2x2 |
35:1310/1550nm | 01: 01:99 02: 02:98 …… 50: 50:50 |
1:1 m x: Customization |
25:250μM Fiber 09:900μM loose fiber | SC: SC/UPC SA: SC/APC 00: no connector |
A: A B: B C:C |
|
| Grade | Port number | Operating wavelength | Coupling ratio | Fiber length | Fiber type | Connect type | Dimension |
EX:WBC-P-12-35-50-1-09-0-B
Fiber Optic Coupler Application:
Wuhan Geehe Service:
1) Quality
Our products widely recognized certifications including EN ISO 9001 and ISO 14001, and the skills of our employees and in-depth expertise of all our market partners allow us to maintain high-quality levels.
2) Customer focus
Geehe maintains long-term customer relationships across more than 50 all over the world representations, The feedback we receive from users is incorporated into product development, quality assurance, and process optimization, and projects are completed quickly and efficiently.
3) Sustainability
Our decisions and actions are ethical, responsible, and balanced. We help to achieve environmental, economic, and social wellbeing for current and future generations within our company and within our community.
