Product Details:
|
| Model Name: | FC Fiber Jumpers Single Mode | Sheath Material: | OFNR Riser |
|---|---|---|---|
| Cable Length: | 3m Or Customerized | Propagation Mode: | Multi Mode,Single Mode |
| Tensile Strength(N): | ≥55 | Cable Diameter: | 0.9mm, 2mm Or 3mm |
| Connector: | FC/UPC To LC/UPC | End-Face Type: | UPC,PC,APC |
| Jacket Color: | Yellow,Orange, White Or Customerized | Standard: | Telcordia GR-326- Core |
| Highlight: | Single Mode FC Fiber Jumpers,PM FC Fiber Optic Jumper,3.0mm Duplex FC Fiber Jumpers |
||
3.0mm Duplex Zipcord Pull-Proof Jacket PM FC Fiber Jumpers Single Mode
1. Basic Introduction:
Polarization Maintaining (PM) Patch Cords come in many flexible configurations, with the choice of connectors. SQS PM Patchcords shows excellent environmental stability, high extinction ratio, high return loss, and low polarization dependence.
A cost-effective solution that provides high bandwidth and transmission rates over long distances. This high-quality multimode fiber optic patch cable is specifically designed for ethernet applications. Each connection has great durability and is resistant to pulls, strains, and impacts during installation.
Our cables are 100% optically inspected and tested for insertion loss before you receive them. A pull-proof jacket design surrounds the Multimode, OM3, 62.5 fiber which is immune to electrical interference.
FC connector is designed specifically with high turbulence performance in mind; it features a unique "floating" ferrule that makes vibrations irrelevant to fiber connections!
2. FC To FC Patch Cord Benefit & Features:
3. Fiber Optic Patch Cord Applications:
4. Specification&Technology Parameter
| Parameters | Value | ||||
| Connector Type | LC/UPC,LC/UPC | ||||
| Center Wavelength(nm) | 1310 or 1550 | ||||
| Max.Insertion Loss(dB) | 0.3 | ||||
| Min.Extinction Ratio(dB) | 23 | ||||
| Min.Return Loss(UPC) (dB) | 55 | ||||
| Min.Return Loss(APC) (dB) | 65 | ||||
| Key Orientation | Slow Axis | ||||
| Axis Alignment(deg) | ±3 | ||||
| Operating Temperature(℃) | -20~+70 | ||||
| Storage Temperature(℃) | -40~+85 | ||||
| FIber Type | PM Panda Fiber | ||||
* For Device with connector.IL is 0.3dB higher,RL is 5dB lower,ER is 2dB lower.
* The default connector key is aligned to the slow axis.
5. FC Connector Specification& Technology Parameter:
| Parameter | Unit | Index | |||
| End-Face Type | PC | UPC | APC | ||
| IL | dB | SM: ≤0.3；MM ≤0.1 | |||
| Repeatability | dB | ≤0.1 | |||
| interchangeability | dB | ≤0.2 | |||
| RL | SM | dB | ≥50 | ≥55 | ≥65 |
| MM | dB | ≥36(Without APC connector) | |||
| Mating Times | ＞1000 | ||||
| Operating Temperature | ℃ | -40~ +80 | |||
6. Our Service:
Your patch cord selection is important to the type of fiber optic network you are working on. Some are ideal for single-mode, while others might be the right for a Multimode installation. Another factor to consider is the polished type when using single-mode cables.
While your patch cord choice is important, it is only one piece of the fiber-optic network to choose from. Take a look at what's available in these other key product categories:
7. Connector Type Abbreviations:
SC - a snap-in style connector. Known for its excellent performance. Referred to as Subscriber Connectors, Square Connectors, or Standard Connectors.
ST - a very popular choice connector for Multimode networks. Also referred to as Straight Tip connectors, they utilize a bayonet-style coupling type, enabling a simple twist-on and twist-off installation.
FC - was at one time the most popular single-mode connector type, but is now typically being replaced by SC and LC connectors. Also known as Ferrule Connectors, they utilize a screw-on coupling type to be used in high-vibration environments and are commonly used for datacom, telecom, measurement equipment, and single-mode lasers.
LC - a small form factor connector—measuring half the size of an SC connector. This is a popular choice for single-mode cables. Also referred to as Lucent Connectors, Little Connectors, or Local Connectors, these snap-in connectors are typically used for high-density connections and are compatible with plug-and-play devices such as SFP modules and XFP transceivers.
