250um Type SM SC APC 1X2 Fiber Coupler 1310nm 1550nm 10/90 Split Ratio 1M Length

250um Type SM SC APC 1X2 Fiber Coupler 1310nm 1550nm 10/90 Split Ratio 1M Length
250um Type SM SC APC 1X2 Fiber Coupler 1310nm 1550nm 10/90 Split Ratio 1M Length 250um Type SM SC APC 1X2 Fiber Coupler 1310nm 1550nm 10/90 Split Ratio 1M Length 250um Type SM SC APC 1X2 Fiber Coupler 1310nm 1550nm 10/90 Split Ratio 1M Length

Large Image :  250um Type SM SC APC 1X2 Fiber Coupler 1310nm 1550nm 10/90 Split Ratio 1M Length

Product Details:
Place of Origin: Wuhan China
Brand Name: Geehe Comm
Certification: CE,ISO9001:2015,ISO14001,RoHS, UL
Model Number: GH-FO-1×2
Payment & Shipping Terms:
Minimum Order Quantity: 100 pcs
Price: Negotiation
Packaging Details: Plastic box per pc with pressure defense sponge, outer carton
Delivery Time: Within 5-7 working days after confirm orders
Payment Terms: L/C, D/A, D/P, T/T,Ali Pay,, Western Union, Cash
Supply Ability: 2,800 Pcs Per Day

250um Type SM SC APC 1X2 Fiber Coupler 1310nm 1550nm 10/90 Split Ratio 1M Length

Description
Model Name: 1X2 Coupler 1310/1550nm SC APC Operating Wavelength: 1310nm,1490nm,1550 Nm
Split Ratio: 50/50,40/60,30/70,20/80,10/90,5/95 Etc Other Types: Singlewindow, Dualwindow,Triplewindow
Function: Fiber Distribution Available Pre-terminated: LC/UPC, LC/APC, SC/UPC, SC/APC, FC/UPC, FC/APC, And ST/UPC
Polarization Alignment: Slow Axis Or Fast Axis Fiber Type: 250um Bare Fiber
Package Type: Steel Tube Configuration Type: 1×2 SC APC
Highlight:

SC APC 1X2 Fiber Coupler

,

250um 1X2 Fiber Coupler

,

1M Length Fiber Optic Coupler

 250um Type SM 1X2 Coupler 1310/1550nm 10/90 Split Ratio 1M Length





Optic Coupler Brief Introduces:



DWC (Dual Window Couplers) are Single Mode Splitters with a defined split ratio from one input fiber to 2 output fibers. This DWC is a 1x2, with 1 input and 2 output fibers with a 90:10 split ratio and 250µm bare fiber. Dual Window Couplers are available with 900µm loose tube single mode fiber or 250µm bare fiber and terminated or unterminated as per your needs. Unconnectorized Dual Window Couplers come with no connectors for easy splicing or connectorization. Connectorized Dual Window Couplers are available with your choice of Fiber Optic Connectors: LC/UPC, LC/APC, SC/UPC, SC/APC, FC/UPC, FC/APC, and ST/UPC.











250um Type SM SC APC 1X2 Fiber Coupler 1310nm 1550nm 10/90 Split Ratio 1M Length 0









1× 2 Fiber Optic Coupler Features& Benefits:

1) Low Insertion loss
2) Low PDL
3) Compact Design
4) Good channel-to-channel uniformity
5) Wide Operating Wavelength: From 1260nm to 1650nm
6) Wide Operating Temperature: From -40°C to 85°C
7) High Reliability and Stability

250um Type SM SC APC 1X2 Fiber Coupler 1310nm 1550nm 10/90 Split Ratio 1M Length 1



Certification and Compliance:

1) GR -1209 - CORE Requirements for Passive Optical Components
2) GR - 1221 - CORE Reliability Assurance Requirements for Passive Optical Components
3) GR - 326 - CORE Requirements for Single-Mode Optical Connectors and Jumpers Assemblies
4) TIA-604 Fiber Optic Connector internateability standard
5)  RoHS Directive on Restriction of Hazardous Substances.

Dual Window Wide Brand Coupler Specification and parameter:

Parameter P A
Operating Wavelength(nm) 1310&1550
Operating Bandwidth(nm) 1310 ± 40nm,1550 ± 40nm
Fiber Type(dB) Corning G652D OR Corning G657 A1
Insertion Loss
(dB)
50/50 ≤3.3 ≤3.5
40/60 3.70~4.40≤2.5 3.50~4.60/≤2.8
30/70 5.00~5.60/≤1.8 4.90~6.10/≤2.1
20/80 6.80~7.40/≤1.2 6.50~7.70/≤1.2
10/90 9.60~10.50/≤0.6 8.80~11.40/≤0.8
5/95 12.70~13.50 /≤0.4 12.05~14.05/≤0.5
3/97 14.60~15.50/≤0.3 13.60~16.05/≤0.4
2/98 16.60~17.90/≤0.25 15.60~18.20/≤0.3
1/99 19.20~20.80/≤0.2 18.80~21.40/≤0.25
PDL(dB) ≤0.1 ≤0.15
Return Loss(dB) ≥50 ≥45
Directivity(dB) ≥55
Operating Temperature(℃) -40 ~ +85



* The above specification is without connector



* Other specifications can be made on customer request





Ordering Information:



WBC- X- X2- 35- XX- X- XX- XX- X
  P: Premium
A: Grade A
X: Customization
12:1x2
22:2x2
35:1310/1550nm 01: 01:99
02: 02:98
……
50: 50:50
1:1 m
x: Customization
25:250μM Fiber 09:900μM loose fiber SC: SC/UPC SA: SC/APC
00: no connector
A: A
B: B
C:C
Grade Port number Operating wavelength Coupling ratio Fiber length Fiber type Connect type Dimension



EX:WBC-P-12-35-50-1-09-0-B





2×2  FIber Optic Coupler Application:



  1. FTTx Systems

  2. LAN, WAN and Metro Networks

  3. Analog/Digital Passive Optical Networks

  4. Long-haul telecommunication

  5. Mini sizes transmitter/receiver module

  6. Optical communication system

  7. Optical communication system

  8. Optical power distribution system

  9. Fiber optic sensors

  10. Optical test system









Wuhan Geehe Service:



1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity


2) Compact Structure
Small size, it can be directly installed in a variety of transfer box and just take up little space


3) Strict Quality Control
We guarantee that every product to the hands of customers is subject to stringent testing standards


4) Fast Delivery

With skilled and stable workers, all the order turnover is fast than the competitors



5) Factory Audit

We cooperate with famous brands and Japanese customers, with 15 years of factory inspection experience and be familiar with the whole inspect process by SGS
