Product Details:
|
| Model Name: | Fiber Optic Rack Mount With Adapter | Structure: | 19'' Rack Mounted |
|---|---|---|---|
| Material: | Zinc-plated Cold Roll Steel Sheet | Rack Color: | Black, White, Grey |
| Height: | 1U, 2U, 3U, 4U, 8U | Ports: | 6, 12, 24, 48, 72, 96, 144 |
| Connector: | SC LC FC ST | Thickness: | 0.8mm,1.0mm, 1.2mm |
| Dimensions (L×W×H) Mm: | 1×32：141×115×18 | Feature: | Waterproof Dustproof |
| Highlight: | 19 Inch FTTH Patch Panel,1U FTTH Patch Panel,FTTH 24 Port Fiber Patch Panel |
||
FTTH 1U 24 Port 19 Inch Single-Mode Fiber Optic Rack Mount With Adapter
Basic Information:
This 19-inch Rack-mount Fiber Optic Distribution Frame for FC,SC,ST,LC adapters. The enclosure is constructed of steel material and its front panel is designed to easily remove for cabling and connector installation.
The front of the enclosure features a push-pin slide-out tray for access to the chassis interior when fiber management is necessary. A complete set of cable management clips are included. The rear panel has all the required cable routing cutouts needed to accommodate all fibers.
The front panel holds a variety of fiber adapter plates allowing the flexibility to order connection types based on your needs.
Benefit& Features:
Application:
Specificaiton&Technology Parameters :
| Parameter | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | 2x4 | 2x8 | 2x16 | 2x32 | ||
| Operating Wavelength(nm) | SDWC:1310&1550；STWC:1310,1490&1550 | ||||||||||
| Port Wavelength Range(nm) | 1310 ±40,1490 ±10 and 1550 ±40 | ||||||||||
| Insertion Loss @1310nm/1550nm | 7.1 | 10.5 | 13.6 | 16.8 | 20.5 | 7.4 | 10.8 | 14.5 | 17.5 | ||
| Uniformity (dB) | 0.6 | 1 | 1.6 | 2 | 1.8 | 0.8 | 1.2 | 1.8 | 2.2 | ||
| PDL@ 1310/1550 nm (dB) | ≤0.3 | ||||||||||
| Input Power (mW) | 250max | ||||||||||
| Operating Temperature (℃) | -40~+85℃ | ||||||||||
| Storage Temperature (℃) | -40~+85℃ | ||||||||||
| Fiber Type | Corning G657A1, 900μm, 2mm, 3mm Loose Tube | ||||||||||
| Dimensions(L×W×H) (mm) | 100×80×10,141×115×18, On request | ||||||||||
* The above specification exclusive connector
19 Inch Rack Specification:
| 19 Inch Rack | LGX | ||||||||||
| Configuration | 1U | 2U | 1U | 2U | |||||||
| Packing Dimensions(mm) | 482.6×278×44 | 482.6×278×88 | 129×125×29 | 129×125×58 | |||||||
| Installation Dimensions (mm) | 462.7×11.0(4-Φ6) | 462.7×27.5(6-Φ6) | 118(2-Φ6) | 118×29.2(2-Φ7) | |||||||
Ordering Information:
| WBC- | X- | X2- | 35- | XX- | X- | XX- | XX- | X | ||
| P: Premium A: Grade A X: Follow Customer's Requirements |
13:1x3 14:1X4 … 232:2 X32 |
35:1310/1550nm | 01: 01:99 02: 02:98 …… 50: 50:50 |
1:1 m x: Follow Customer's Requirements |
25:250μM Fiber 09:900μM Loose Fiber |
SC: SC/UPC SA: SC/APC 00:no connect |
D:D 1U: J1 2U: J2 |
|||
| Grade | Port Number | Operation Wavelength | Coupling Ratio | Fiber Length | Fiber Type | Connector Type | Dimension | |||
Geehe Factory Fiber Patch Panel Performance:
