Multi Mode Duplex OFNR 5M LC SC Fiber Optic Patch Cord

Multi-Mode Duplex 5M OFNR Yellow Jacket Fiber Jumper Patch Cord LC SC

1.Brief Introduction:

Geehe fiber optic patch cords provide the ideal medium for all your fiber optic interconnect applications. They are designed, manufactured, network equipment manufactured, wholesale, and tested according to protocol and performance dictated by the industry standards.

The quality of the components used to build our fiber optic patch cords ensures long-lasting and high repeatability connections.

Geehe also supply offers a wide variety of connector options, jacket colors, and diameter as well as different flammability ratings, and has the capability to custom build to meet your most stringent mechanical and performance specifications. All Geehe patch cords have an identification label and have a unique serial number assigned to them. On each of these labels the part number, serial number, and the length of the patch cord are displayed for easy product recognition and traceability.

2. Fiber Optic Patch Cord LC To SC Benefit & Features:

• Pre-terminated with LC or SC connectors
• Meet the TIA/EIA industry standard with a maximum insertion loss of 0.2dB
• Polished for consistent performance
• TIA-492AAAC standard for OM3 50/125 multimode cable
• Minimum bend radius: 1.18-inch (30mm)
• Maximum Connector Loss: 0.50 dB
• 10 Gb/s application support
• OFNR jacket complies with stringent building codes
• Used primarily for high bandwidth, long-distance telecommunications
• UL rating for safety

3.Fiber Optic Patch Cord Applications:

•  Central Office Connections (Both-End Jumpers, Riser Rated or Plenum)
•  NOC’s (Riser-Rated, Plenum, Indoor/Outdoor)
•  Business-to-Fiber Network connections
•  FTTx

4.Specification&Technology Parameters

* For Device with connector.IL is 0.3dB higher,RL is 5dB lower,ER is 2dB lower.

* The default connector key is aligned to the slow axis.

5. Fiber patch cord LC to SC Specification& Technology Parameter​:

5.LC Connector Ordering Information:

* EX:OFC-D-LA-LA-09-1-1.0

6.SC Connector Ordering Information:

7. How to choose Fiber patch cords?

1) Fiber Cable Mode: Single Mode or Multimode

The mode of fiber patch cables indicates how light beams travel within the fiber. There are two fiber cable modes: single mode and multimode.

2) Number of Fiber Strands: Simplex or Duplex

According to the number of fiber strands, there are simplex and duplex fiber patch cord. As shown in Figure 2, simplex fiber patch cord contains one single strand of fiber with one simplex connector on each end. It can be linked with a pair of BiDi transceiver modules featuring with one port. Whereas duplex fiber patch cord consists of two strands of glass or plastic with one duplex connector (or considered as two simplex connectors). It is often linked with common transceivers or dual fiber BiDi transceivers.

3) Choose the Right Cable Jacket Type (PVC/LSZH/OFNP/Armored)
Usually, there are three cable jacket types: Polyvinyl Chloride (PVC), Low Smoke Zero Halogen (LSZH) and Optical Fiber Nonconductive Plenum (OFNP). You can see there features in figure below and choose the right one for your network.

4)Connector Type: LC, SC, ST or Others
There are many connector types used in fiber patch cables such as LC, SC, ST, MTP or MPO listed in this article How Many Fiber Connector Types Do You Know? Aside from these connectors, there is a latest connector design called MDC connector, which enables the highest achievable connector density by delivering a 3X advantage over a standard LC connector. The different connector types are to plug into different interfaces, so you’d better affirm the interface type of the devices you are using the first time.

5)Choose the Right Connector Polish Type (UPC/APC)
Since the loss of the APC connector is lower than UPC connectors, usually, the optical performance of APC connectors is better than UPC connectors. In the current market, the APC connectors are widely used in applications such as FTTx, passive optical network (PON) and wavelength-division multiplexing (WDM) that are more sensitive to return loss. But APC connector is usually expensive than UPC connector, so you should weigh the pros and cons. With those applications that call for high precision optical fiber signaling, APC should be the first consideration, but less sensitive digital systems will perform equally well using UPC. Usually, connector color of APC patch cable is green, and of UPC patch cable is blue.

8. Geehe Service:

• Our pre-terminated cables are very cost-effective and save you money in numerous ways
• Eliminating your labor costs associated with installing connectors in the field
• Eliminating the need for technicians to spend time and money re-doing work that has failed
• Reducing the cost of additional connectors and supplies to replace failed splices.
• The pre-terminated cables can be manufactured to any length needed.
