Product Details:
|
| Model Name: | Single Mode Patch Cord SC-SC | Cable Diameter: | 3.0mm |
|---|---|---|---|
| Cable Material: | PVC,OFNR | Polishing: | UPC,APC,PC |
| Cable Grade: | FDDI Riser Rated OFNR | Cable Length: | 1M,2M,3M...customize |
| Cable Dimensions: | 3.0mm | Cable Sheath Color: | Yellow,Orange, Lime Green Etc |
| Fiber Type: | SM,MM | ||
| Highlight: | 3.0mm sc to sc single mode patch cord,3.0mm sc to sc fiber patch cable,3.0mm optical patch cord |
||
Indoor High-Reliability Yellow Jacket Fiber Optic Simplex Single Mode Patch Cord SC-SC
1.Fiber Patch Cord Basic Introduction:
An SC/UPC to SC /UPC fiber optic patch cord is used to connect fiber optic equipment to equipment or patch panel to equipment, UPC stands for Ultra Physical Contact and represents one of the best ways of polishing for fiber ferrules, assuring a return attenuation greater than 50dB for single-mode connections.
Backed by Lifetime Warranty, our SC-SC Multimode Fiber Patch cable is guaranteed to provide long-lasting dependability and top-quality performance.
2.Fiber Optic Patch Cord SC To SC
3. Single Mode SC To SC Patch Cord Application:
4.Specification&Technology Parameters
| Parameters | Value | ||||
| Connector Type | LC/UPC,LC/UPC | ||||
| Center Wavelength(nm) | 1310 or 1550 | ||||
| Max.Insertion Loss(dB) | 0.3 | ||||
| Min.Extinction Ratio(dB) | 23 | ||||
| Min.Return Loss(UPC) (dB) | 50 | ||||
| Min.Return Loss(APC) (dB) | 60 | ||||
| Key Orientation | Slow Axis | ||||
| Axis Alignment(deg) | ±3 | ||||
| Operating Temperature(℃) | -20~+70 | ||||
| Storage Temperature(℃) | -40~+85 | ||||
| FIber Type | PM Panda Fiber | ||||
* For Device with connector.IL is 0.3dB higher,RL is 5dB lower,ER is 2dB lower.
* The default connector key is aligned to the slow axis.
5. Fiber patch cord SC Specification& Technology Parameter:
| Parameter | Unit | Index | |||
| End-Face Type | PC | UPC | APC | ||
| IL | dB | SM: ≤0.3；MM ≤0.1 | |||
| Repeatability | dB | ≤0.1 | |||
| interchangeability | dB | ≤0.2 | |||
| RL | SM | dB | ≥50 | ≥55 | ≥65 |
| MM | dB | ≥36(Without APC connector) | |||
| Mating Times | ＞1000 | ||||
| Operating Temperature | ℃ | -40~ +80 | |||
* EX:OFC-D-LA-LA-09-1-1.0
6. More connectors are available
