Product Details:
|
Model Name: | Fiber Optic Splitter Single Mode | Channel Number: | 1×16 |
---|---|---|---|
FIber Mode: | Single Mode | Cable Diameter: | 250um |
Color: | White And Colorful | Fiber Length: | Customized Length1M, 1.5M, 2M, 2.5M, Custom |
Low Insertion Loss: | ≤ 4.2dB | Port Wavelength: | 1260 - 1650nm |
PLC Casing Type: | Micro PLC | Cable Type: | 0.9MM, G657A Fiber |
Highlight: | 0.9mm 1x16 Plc Splitter,Single Mode 1x16 Plc Splitter,DWDM 1x16 Plc Splitter |
DWDM Steel Tube package 0.9mm cable 1x16 Fiber Optic Splitter Single Mode
Basic Information:
Singlemode G.657A1 fiber, 250μm bare fiber, 1260~1650nm, Blockless Type PLC Splitter apply for PON systems to acknowledge optical sign force parting as a minimal effort arrangement.
Geehe's PLC splitters are available in tube, box, cassette, and rack mount configurations, from 1 to 32 splits, even or customized splits, single and multimode, with any connector type.
Blockless PLC Features& Benefits:
Application&Standard:
Specification& parameters
Parameter | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | 2x4 | 2x8 | 2x16 | 2x32 | ||
Operating Wavelength(nm) | 1260~1650 | ||||||||||
Port Wavelength Range (nm) | 1310 ±20,1490 ±10 and 1550 ±20 | ||||||||||
Insertion Loss @1310nm/1550nm | 7.1 | 10.5 | 13.6 | 16.8 | 20.5 | 7.4 | 10.8 | 14.5 | 17.5 | ||
Uniformity (dB) | 0.5 | 0.8 | 1 | 1.2 | 1.8 | 1.2 | 1.5 | 1.8 | 2 | ||
PDL @ 1310/1550 nm (dB) | ≤0.3 | ||||||||||
Return Loss@ 1310/1551 nm (dB) | ≤-55 | ||||||||||
Input Power (mW) | 250max | ||||||||||
Operating Temperature (℃) | -40~+85℃ | ||||||||||
Storage Temperature (℃) | -40~+85℃ | ||||||||||
Fiber Type | Corning G657A1 |
1×32 Splitter Package Dimensions:
40x4x4 | 1x4 | 1x8 | 2x4 | 2x8 | |
50x7x4 | 1x16 | 2x16 | |||
60x7x6 | 1x32 | 2x32 | |||
60x12x4 | 1x64 |
Ordering Information:
PLC | AAA | O | CC | 0 | EE |
104=1x4 108=1x8 …… 164=1x64 204=2x4 …… 232=2x32 | 0=250um ribbon | 05=0.5m 10=1.0m 15=1.5m 20=2.5m | 1=900µm loose | 05=0.5m 10=1.0m 15=1.5m 20=2.5m | |
Configuration | Input Fiber Type | Input Fiber Length | Output Fiber Length | Output Fiber | |
