SM LC To LC 10M Uniboot Patch Cord For Fiber Network

SM LC To LC 10M Uniboot Patch Cord For Fiber Network
SM LC To LC 10M Uniboot Patch Cord For Fiber Network SM LC To LC 10M Uniboot Patch Cord For Fiber Network SM LC To LC 10M Uniboot Patch Cord For Fiber Network SM LC To LC 10M Uniboot Patch Cord For Fiber Network SM LC To LC 10M Uniboot Patch Cord For Fiber Network

Large Image :  SM LC To LC 10M Uniboot Patch Cord For Fiber Network

Product Details:
Place of Origin: Hubei, China
Brand Name: Geehe
Certification: ISO9001:2015,Realiability Reports
Model Number: GH-OP-MM-0010
Payment & Shipping Terms:
Minimum Order Quantity: 200 pcs
Price: Negotiation
Packaging Details: PE bags with thick outer cartons,follow customers' requirements
Delivery Time: With 5-7 working days after confirmed the order
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 280,000 pcs/ month

SM LC To LC 10M Uniboot Patch Cord For Fiber Network

Description
Model Name: Duplex LC To LC Fiber Patch Cable Fiber Counts: Duplex
Fiber Type: SM Sheath Material: PVC/LSZH
Connectors: LC To LC Cable Length: 0.5m/1m/1.5m Or Customized
Endface Of The Connector: PC/UPC/APC Diameter Of The Cable: 0.9/2.0/3.0/4.8/7.0
Fiber Color: Yellow/orange/Aqua/Red Customerized Impact Cycle: 1500
Highlight:

10M Uniboot Patch Cord

,

LC To LC Uniboot Patch Cord

,

Duplex SM Patch Cord

Fiber Optic Cable Assembly SM Patch Cord LC To LC 10M Uniboot Patch Cord





1. Fiber Patch Cord Basic Introduction:



Duplex LC Uniboot Push-Pull connector gives you the option to change polarity with ease, it also has no loose pieces that could be dropped or lost when changing polarity with ease, it also has no loose pieces that could be dropped or lost when changing polarity. The LC Uniboot Push-Pull Duplex fiber optic patch cords are constructed with a 2.0mm 2-fiber round unitary cable available in plenum(OFNP) or low smoke zero halogen (LSZH) rated jacket materials to meet local ordinances. By using the 2.0mm cable which reduces cable volume by 50% the LC Uniboot Push -pull fiber optic patch cords are ideal for reducing cabling congestion in extremely high-density patch fields.



These LC Uniboot patch cords are available in OM5+, OM4+, OM3, and OS2 fiber types with high-performance insertion loss essential for today's high-speed systems requiring very low connector insertion loss.







2. Uniboot Fiber Optic Patch Cord Benefit & Features:

  • Pull Tab Design -- allows the LC Optical Cable easily plugged from the SFP connector or network adapter
  • Polarity Change Uniboot LC Connector -- with this Polarity Change Uniboot LC optic cables, you can change the polarity easily yourself without tools, ONLY ONE Fiber Cover, SAVE More Space
  • 10m long LC ethernet cable, 50/125 LSZH 2.0mm OD Fiber Patch Cable, OM3 MM Duplex LC-LC Fiber Optic Cables
  • Patch cords using Uniboot technology combine, modularity, flexibility with easy insertion and removal from connectivity
  • Uniboot connectors feature an adjustable polarity via a manual and independent rotation of each single connector body without exposing the fibers
  • Uniboot technology features a push-pull mechanism operated by squeezing the connector boot
  • Adjustable connector pitch between 5.25 and 6.25mm

SM LC To LC 10M Uniboot Patch Cord For Fiber Network 0







3. Uniboot Patch Cord Applications:



Uniboot Patch Cord has been designed for use in high-density data center applications. The reduced cable diameter improves cable management by reducing the total volume of cable without reducing fiber count. It is the perfect solution for improving accessibility in high-density cross-connect systems. The polarity of the Uniboot patch cord can also be switched at the point of installation, making it a flexible choice for any fiber network.





SM LC To LC 10M Uniboot Patch Cord For Fiber Network 1





4. Specification&Technology Parameters



Construction
Fiber Count 2- Fiber Round
Cable Jacket Ratings Plenum (OFNP)
Low Smoke Zero Halogen (LSZH)
Fiber Types Singlemode: OS2 9/125um
Multimode: OM3 50/125um OM4/4+50/125um OM5+ 50/125um
Connector Types Duplex LC Uniboot
Jacket Color OS1/OS2: Yellow OM3: Aqua OM4: Aqua OM4+:Aqua OM5+:Lime Green
Physical Properties
Cable outside diameter (OD) 2.0mm
Bend radius (min) 40mm
Connector durability 500 cycles
Bend radius (min)(Long- term) 20mm (40mm)
Optical Properties
Connector insertion loss MM: 0.15dB max (Optimized IL) 0.10dB max (Ultra-low IL) 0.25dB max (Optimized IL)
SM: 0.25 dB max ( Optimized IL)
Connector return loss 26dB min (MM) 55dB min (SM) 65dB min (SM/APC)
Environmental Properties
Storage and shipping temperature -40℃-+70 ℃
Operating and installation temperature -40℃-+70 ℃







5. Ordering Information



Code Fiber Type Cable Type Jacket Material Color Length (m)
P 3 OM3 AR2 Round 2mm L LSZH Y Yellow 1
  4 OM4 AX2 Round 2.4mm R OFNR A Aqua 2
  7 G.657A1     P OFNP E Erika Violet 3
  8 G.657A1             5
                  10





Legacy ordering information





Connector End Mode Cable Configuration Cable Colour Cable Diameter Cable Length (m)
LC to LC 9 OS1/OS2 D Duplex Y Yellow 2.4mm 1
7A1 G.657A1 DR Duplex Riser A Aqua 3.0mm 2
7A2 G.657A2 DP Duplex Plenum P Purple   3
OM3 OM3           5
OM4 OM4           10




6. Why Geehe Comm?

  • ​Expert advice
  • Own factory& operate
  • Secure online shopping 24/7
  • Lightning-fast delivery worldwide
  • Warranty & peace of mind return policy
  • Over 3000 quality products in stock ready to go
  • All products are approved as per international standards
  • ISO 9001/RoHS approved supplier
