Product Details:
|
| Model Name: | Multimode Fiber Jumper | Connectors: | LC/SC/ST/FC/LSH/MU/MTRJ |
|---|---|---|---|
| Polishing: | APC UPC,PC | Fiber Mode: | Duplex, Simplex |
| Cable Diameter: | 0.9mm,2.0mm,3.0mm | Cable Material: | PVC/LSZH/OFNR |
| Fiber Grade: | G.652.D | Jacket Color: | Blue |
| Fiber Cable Length: | 1m,2m,3m,5m, Customized | Test Requirements: | 100% 3D Test |
| Highlight: | 4 Meter Multimode Fiber Jumper,LC to SC Multimode Fiber Jumper,G.652.D Networks Fiber Patch Cables |
||
4 Meter Duplex LC to SC Multimode Fiber Jumper For Fiber Networks
1. Brief Introduction:
Multimode Fiber Optic Cables – also referred to as patch cables or jumper cables – connects devices in short proximity to each other. To reduce installation time, the cable ends are terminated, which also ensures a higher-quality product.
Geehe supplies multimode fiber optic cable, single-mode fiber optic cable patch cords in a large variety of colors and lengths.
LC to SC Fiber Optic Patch Cord is designed to accommodate10 Gigabit Ethernet up to 300 meters, with a High-Quality PVC Jacket, LSZH, durable for indoor use. Low Loss: Insertion loss(dB)≤0.2, Return loss(dB)≥30.
2. Fiber Optic Patch Cord LC To SC Benefit & Features:
3. Fiber Optic Patch Cord Applications:
4. Specification&Technology Parameters
| Parameters | Value | ||||
| Connector Type | LC/UPC,LC/UPC | ||||
| Center Wavelength(nm) | 1310 or 1550 | ||||
| Max.Insertion Loss(dB) | 0.3 | ||||
| Min.Extinction Ratio(dB) | 23 | ||||
| Min.Return Loss(UPC) (dB) | 50 | ||||
| Min.Return Loss(APC) (dB) | 60 | ||||
| Key Orientation | Slow Axis | ||||
| Axis Alignment(deg) | ±3 | ||||
| Operating Temperature(℃) | -20~+70 | ||||
| Storage Temperature(℃) | -40~+85 | ||||
| FIber Type | PM Panda Fiber | ||||
* For Device with connector.IL is 0.3dB higher,RL is 5dB lower,ER is 2dB lower.
* The default connector key is aligned to the slow axis.
5. Fiber patch cord LC to LC Specification& Technology Parameter:
| Parameter | Unit | Index | |||
| End-Face Type | PC | UPC | APC | ||
| IL | dB | SM: ≤0.3；MM ≤0.1 | |||
| Repeatability | dB | ≤0.1 | |||
| interchangeability | dB | ≤0.2 | |||
| RL | SM | dB | ≥50 | ≥50 | ≥50 |
| MM | dB | ≥36(Without APC connector) | |||
| Mating Times | ＞1000 | ||||
| Operating Temperature | ℃ | -40~ +80 | |||
6. LC Connector Ordering Information:
| OFC | -X | -XX | -XX | -XX | -X | -X |
| S: Simplex D: Duplex |
LA:LC/APC LC:LC/UPC LP:LC/PC | LA:LC/APC LC:LC:UPC LP:LC/PC | 09:0.9mm 20:2.0mm 30:3.0mm | 0:G652D 1:G657A 2:50/125 3:62.5/125 4:others | 0.5:0.5m 1.0:1.5m 10:10.0m |
|
| Fiber Mode | Connector Type | Connector Type | Cable Diameter | Flange Type | Fiber Length |
* EX:OFC-D-LA-LA-09-1-1.0
7. SC Connector Ordering Information:
| OFC | -X | -XX | -XX | -XX | -X | -X |
| S: Simplex D: Duplex |
SA:LC/APC SC:LC/UPC SP:LC/PC | SA:LC/APC SC:LC:UPC SP:LC/PC | 09:0.9mm 20:2.0mm 30:3.0mm | 0:G652D 1:G657A 2:50/125 3:62.5/125 4:others | 0.5:0.5m 1.0:1.5m 10:10.0m |
|
| Fiber Mode | Connector Type | Connector Type | Cable Diameter | Flange Type | Fiber Length |
7. Geehe Service:
We provide OEM service, the following items can be customized:
1. Connector: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA Connector Optional.
2. Ferrule end-face: PC, UPC, APC optional.
3. Fiber mode: 9/125um Singlemode, Multimode(OM2, OM3, OM4, OM5) optional.
4. Fiber Count: simplex, duplex optional.
5. Cable diameter: 3.0mm, 2.8mm, 2.0mm, 1.8mm, 1.2mm, 0.9mm optional.
6. Cable color: Yellow, ivory, white, blue, orange, aqua, pink color optional.
7. Cable length: 0.5m to 50m optional.
8. Cable jacket: PVC or LSZH optional.
