Product Details:
|
| Model Name: | 1×8 PLC Fiber Optic Splitter | Cable Type: | 9/125um Single-mode |
|---|---|---|---|
| PLC Casing Type: | Micro PLC | Splitting Ratio: | 1x16，1×8 |
| Cable Diameter: | 900um | Fiber Length: | Customized Length1M, 1.5M, 2M, 2.5M, Custom |
| Fiber Type: | G657 Grade A Optical | Port Wavelength: | 1310-1550nm |
| Package: | Steel Tube, ABS Black Box, Rack, Module | Length: | 1m Or 1.5m |
| Highlight: | SC UPC PLC Fiber Optic Splitter,Blockless Type PLC Fiber Optic Splitter,Fiber Optic PLC Splitter 1×6 |
||
1 ×6, 1×8 Blockless Type Mini Mode SC UPC PLC Fiber Optic Splitter
Quick Overview:
Planar lightwave circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations.
Blockless PLC splitter has stronger fiber protection than bare fiber splitter, which is a miniaturization result of cassette splitter. It's mainly used for various connection and distribution boxes or network cabinets.
PLC Splitter Features&Benefit:
Application&Standard:
Specification& parameters
| Parameter | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | 2x4 | 2x8 | 2x16 | 2x32 | ||
| Operating Wavelength(nm) | 1260~1650 | ||||||||||
| Port Wavelength Range (nm) | 1310 ±20,1490 ±10 and 1550 ±20 | ||||||||||
| Insertion Loss @1310nm/1550nm | 7.1 | 10.5 | 13.6 | 16.8 | 20.5 | 7.4 | 10.8 | 14.5 | 17.5 | ||
| Uniformity (dB) | 0.5 | 0.8 | 1 | 1.2 | 1.8 | 1.2 | 1.5 | 1.8 | 2 | ||
| PDL @ 1310/1550 nm (dB) | ≤0.3 | ||||||||||
| Return Loss@ 1310/1551 nm (dB) | ≤-55 | ||||||||||
| Input Power (mW) | 250max | ||||||||||
| Operating Temperature (℃) | -40~+85℃ | ||||||||||
| Storage Temperature (℃) | -40~+85℃ | ||||||||||
| Fiber Type | Corning G657A1 | ||||||||||
PLC Splitter Package Dimensions:
| WxHxD(mm) | Port | ||||
| 60x7x4 | 1x4 | 1x8 | 2x4 | 2x8 | |
| 60x12x4 | 1x16 | 2x16 | |||
| 80x12x6 | 1x32 | 2x32 | |||
| 100x40x6 | 1x64 | ||||
Ordering Information:
| PLC | AAA | B | CC | D | EE | FF | GG |
| 104=1x4 108=1x8 …… 164=1x64 204=2x4 …… 232=2x32 | 1=900µm loose | 05=0.5m 10=1.0m 15=1.5m 20=2.5m | 1=900µm loose | 05=0.5m 10=1.0m 15=1.5m 20=2.5m | SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector | SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector | |
| Configuration | Input Fiber Type | Input Fiber Length | Output Fiber Length | Output Fiber | Input Connector | Output Connector |
Compliance:
- Telcordia GR-1209-CORE
- Telcordia GR-1221-CORE
- RoHS
