1× N Bare 250um Steel Tube Optical Splitter Without Connector

Large Image : 1× N Bare 250um Steel Tube Optical Splitter Without Connector

Product Details:

Place of Origin:	China Mainland
Brand Name:	Wuhan Geehe
Certification:	ISO9001:2015,UL, RoHS
Model Number:	GH-PLC-1XN-009

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	Negotiation
Packaging Details:	Plastic box per pc with Pressure defense sponge, outer carton
Delivery Time:	7-9 Working days if you confirm order today
Payment Terms:	T/T,L/C,, Western Union, D/P, D/A，Sinosure
Supply Ability:	6,600 Pcs/day

Contact Now

1× N Bare 250um Steel Tube Optical Splitter Without Connector

Description

Model Name:	Optic Fibre Splitter	Cable Type:	9/125um Single-mode
PLC Casing Type:	Micro PLC	Splitting Ratio:	1×N
Cable Diameter:	125um	Fiber Length:	Customized Length1M, 1.5M, 2M, 2.5M, Custom
Fiber Type:	G657 Grade A Optical	Port Wavelength:	1310-1550nm
Package:	Steel Tube, ABS Black Box	Length:	1m Or 1.5m
Highlight:	250um Steel Tube Optical Splitter , 1xN Bare PLC Fiber Splitter , FTTX Network PLC Fiber Optic Splitter

1× N Bare 250um Steel Tube Optic Fibre Splitter Without Connector

Basic Information :

1xN Bare PLC Fiber Splitter
1X2 PLC splitter, uniform distribution of optical signal
Small size, with the splitter type of steel tube, bare fiber
Ideal for EPON, GPON, FTTH/FTTX network
High Environmental Stability

PLC Splitters provide a cost effective and space saving product suitable to the ever changing networking requirements. With it's compact size, these splitters can be utilized in in-ground and aerial pedestals as well as rack mount systems.

We can supply specification:1×2,1×4,1×8,1×16,1×32,1×64,2×4,2×8,2×16,2×32.

1× N Bare 250um Steel Tube Optical Splitter Without Connector 0

Bare Fiber PLC Features&Benefit:

Singlemode PLC Splitters in a variety of package types and configurations
Optical performance 100% factory tested
Installed in the cable connector box;
Installed in the module box;
Installed in the distribution box.
Telcordia GR-CORE 1221 certified

1× N Bare 250um Steel Tube Optical Splitter Without Connector 1

Application&Standard:

Optical Signal Distribution
Data Communications
Lan and CATV System
FTTX Deployment
FTTH Network
DWDM and CWDM Systems
Measuring System and Laser System

1× N Bare 250um Steel Tube Optical Splitter Without Connector 2

Specification& parameters

Parameter	1x4	1x8	1x16	1x32	1x64	2x4	2x8	2x16	2x32
Operating Wavelength(nm)	1260~1650
Port Wavelength Range (nm)	1310 ±20,1490 ±10 and 1550 ±20
Insertion Loss @1310nm/1550nm	7.1	10.5	13.6	16.8	20.5	7.4	10.8	14.5	17.5
Uniformity (dB)	0.5	0.8	1	1.2	1.8	1.2	1.5	1.8	2
PDL @ 1310/1550 nm (dB)	≤0.3
Return Loss@ 1310/1551 nm (dB)	≤-55
Input Power (mW)	250max
Operating Temperature (℃)	-40~+85℃
Storage Temperature (℃)	-40~+85℃
Fiber Type	Corning G657A1

PLC Splitter Package Dimensions:

WxHxD(mm)	Port
60x7x4	1x4	1x8	2x4	2x8
60x12x4	1x16		2x16
80x12x6	1x32		2x32
100x40x6	1x64

Ordering Information:

PLC	AAA	B	CC	D	EE	FF	GG
	104=1x4 108=1x8 …… 164=1x64 204=2x4 …… 232=2x32	1=900µm loose	05=0.5m 10=1.0m 15=1.5m 20=2.5m	1=900µm loose	05=0.5m 10=1.0m 15=1.5m 20=2.5m	SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector	SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector
	Configuration	Input Fiber Type	Input Fiber Length	Output Fiber Length	Output Fiber	Input Connector	Output Connector

Geehe Comm Service:

Provide the highest quality of products
Continuous improvement; accepting new challenges
Innovating new processes, and creating new products for the benefit of our customers
Consultative service and strive to ensure a positive and productive experience
Efficient use of all transportation modes and transit times
Greater visibility and real-time information
