3M SC-LC 9/125 OS2 Singlemode PVC OFNR Duplex Fiber Patch Cable

3M SC-LC 9/125 OS2 Singlemode PVC (OFNR) Duplex Fiber Patch Cable

1. Fiber Patch Cord Basic Introduction:

Geehe offers a variety of multimode fiber patch cables with connector types that range from LC, SC, and ST, to MPO and MTP. CBS provides plenum-rated and riser-rated fiber patch cords suitable for high-speed bandwidths, including OM1 patch cable 62.5/125, OM2 cord 50/125, OM3 patchcord 50/125, and OM4 50/125, which are optimal for Gigabit Ethernet and 10G network applications.

Boot styles are available in standard, duplex, and uniboot, and fiber cables come in aqua or orange. Multimode LC-LC fiber optic patch cables have a larger diameter glass core than single-mode cables and are typically used for shorter distances. Multi-mode cables send multiple light signals, whereas, single-mode cables send one signal, this allows a multitude of assemblies to operate from less expensive light sources. They are 50/125µ. Common connectors are ST, LC, SC, and FC. Our 50/125µ fiber cables can support gigabit ethernet up
to 550 meters.

2. Fiber Optic Jumper Benefit & Features:

• Fiber Construction
  Our standard patch cables are available in several different lengths and connector types. These fibers have a 900 µm jacket surrounded by a layer of Aramid yarn for extra protection. A 2.5 mm PVC cable jacket provides additional environmental protection.
• Custom Singlemode Patch Cables
  Use Model Number F-PATCH-CUSTOM to configure a custom fiber-optic patch cord using these fibers. You can specify the fiber type, length, jacketing, and input and output connectors.
• Excellent Performance
  Our Standard Patch Cables exhibit low attenuation while utilizing step-index fibers and also have a uniform core refractive index and a matched-clad profile.
• Popular Versions Available Off-the-shelf
  We carry many standard fiber optic patch cables available off-the-shelf for operating wavelengths of near UV 300, visible 488/514, 633, infrared 780, 820, 980, 1060, or 1300/1550 nm. If there is not a standard patch cable available for your application

3. Fiber Optic Jumper Applications:

• Telecommunication Networks
• Cable Television (CATV)
• Premises Distribution
• Local Area Networks (LAN)
• Fiber -to the- Home (FTTx)
• Sensors
• Instrumentation
• Device pigtails
• Light delivery

4. Specification&Technology Parameters

5. Ordering Information

Ordering information

6.  Options Available

-- LC Custom fiber optic jumper options include.
-- LC/PC (Physical Contact) Polish
-- LC/UPC (Ultra Physical Contact) polish
-- LC/APC (Angled Physical Contact) polish

Jacket: Riser (OFNR), Plenum (OFNP), Low Smoke Zero Halogens (LSZH), PVC

Diameter: 0.9mm (900µm), 1.6mm, 1.8mm, 2.0mm, 3.0mm

Jacket Colors: Aqua, Orange, Green, Red, Blue, Gray, Black, Yellow
LC Multimode 62.5/125µm MMF Fiber (Corning Fiber Optic Cable)
LC Multimode 50/125µm MMF OM2 Fiber (Corning Fiber Optic Cable)
LC Multimode 50/125µm MMF OM3 10Gb Laser Optimized Fiber (Corning Fiber)
LC Simplex cables or LC Duplex Cables are also available in optional colors.
LC Standard boot, LC 45° angled boot, LC 90°angled boot, or short boot options.
Corning Fiber Optic Cable, or Fiber One Fiber.
Call us today to speak with one of our qualified salespeople to help answer any questions.
