Yellow Jacket 62.5 125 Multimode 100M FC APC To SC Fiber Patch Cord

Yellow Jacket 62.5 125 Multimode 100M FC APC To SC Fiber Patch Cord

1. Fiber Patch Cord Basic Introduction:

Geehe fiber optic cable assemblies are ideal for supporting duplex and simplex fiber applications over extended distances and next-generation backbones. Geehe cable assemblies feature premium fiber that meets IEC - 60793-2-10, TIA-492AAAC (OM3), and TIA-492AAAD (OM4) specifications. In addition, these assemblies offer a superior connector polish that meets stringent Telcordia and ISO/IEC specifications for end-face geometry and exceeds all ANSI/TIA and ISO/IEC insertion loss and return loss requirements. Geehe's single-mode jumpers and pigtails are also available in angled polish (APC) for FTXX, PON, POL, CATV, LAN, and WAN.

Our fiber optic patch cords use only the highest-grade connectors.

They are also suitable as reference cables when performing fiber loss testing. The single-mode cables have a UPC polish and provide back reflection less than -50dB. Multimode cables are 62.5/125, the standard for network equipment, and use the highest grade connectors and a PC polish. All patch cords are 2 meters in length.

This Single-Mode patch cord uses a 9/125µm fiber optic patch cable with dual FC/UPC connectors on one end and dual SC/APC connectors on the other.

2. Fiber Optic Jumper Benefit & Features:

• Fiber Construction
  Our standard patch cables are available in several different lengths and connector types. These fibers have a 900 µm jacket surrounded by a layer of Aramid yarn for extra protection. A 2.5 mm PVC cable jacket provides additional environmental protection.
• Custom Singlemode Patch Cables
  Use Model Number F-PATCH-CUSTOM to configure a custom fiber-optic patch cord using these fibers. You can specify the fiber type, length, jacketing, and input and output connectors.
• Excellent Performance
  Our Standard Patch Cables exhibit low attenuation while utilizing step-index fibers and also have a uniform core refractive index and a matched-clad profile.
• Popular Versions Available Off-the-shelf
  We carry many standard fiber optic patch cables available off-the-shelf for operating wavelengths of near UV 300, visible 488/514, 633, infrared 780, 820, 980, 1060, or 1300/1550 nm. If there is not a standard patch cable available for your application
• Fiber Type -- OM1, OM3, OM4, OS1/OS2

3. Fiber Optic Jumper Applications:

• Telecommunication Networks
• Cable Television (CATV)
• Premises Distribution
• Local Area Networks (LAN)
• Fiber -to the- Home (FTTx)
• Sensors
• Instrumentation
• Device pigtails
• Light deliver

4. Specification&Technology Parameters

5. Ordering Information

Legacy ordering information

6.  Options Available

-- LC Custom fiber optic jumper options include.
-- LC/PC (Physical Contact) Polish
-- LC/UPC (Ultra Physical Contact) polish
-- LC/APC (Angled Physical Contact) polish

Jacket: Riser (OFNR), Plenum (OFNP), Low Smoke Zero Halogens (LSZH), PVC

Diameter: 0.9mm (900µm), 1.6mm, 1.8mm, 2.0mm, 3.0mm

Jacket Colors: Aqua, Orange, Green, Red, Blue, Gray, Black, Yellow
LC Multimode 62.5/125µm MMF Fiber (Corning Fiber Optic Cable)
LC Multimode 50/125µm MMF OM2 Fiber (Corning Fiber Optic Cable)
LC Multimode 50/125µm MMF OM3 10Gb Laser Optimized Fiber (Corning Fiber)
LC Simplex cables or LC Duplex Cables are also available in optional colors.
LC Standard boot, LC 45° angled boot, LC 90°angled boot, or short boot options.
Corning Fiber Optic Cable, or Fiber One Fiber.
Call us today to speak with one of our qualified salespeople to help answer any questions.
