Product Details:
|
| Model Name: | Fiber Optic Adapter FC-FC | Fiber Counts: | Duplex |
|---|---|---|---|
| Adapter Insert Material: | Zirconia/Ceramic, Metal | Housing Material: | Metal, Plastic |
| Connector Type: | FC To FC | Fiber Mode: | Single Mode,Multi Mode |
| Durability: | >1000 Mating Times | Operating Temperature: | -40~75℃ |
| Adapter Mounting Type: | Reduced Flange | ||
| Highlight: | Green Multimode Fiber Optic Adapter,Fiber Optic Adapter FC to FC,Fiber Optic Adapter With Rectangular Flange |
||
FC/UPC to FC/UPC Simplex Fiber Optic Adapter Types Mating Sleeve With Flange
1. Product Overview:
FC-FC Optical Fiber Mating Adapter/Sleeve is a wide key adapter used to connect two FC/PC or two FC/APC fibers together with low loss. This model has an FC female fiber connector on each end. It Can be used for single-mode or multi-mode connectorized fibers.
This FC Simplex Adapter allows you to patch together FC connectors or FC fiber patch cables quickly. The FC coupler is particularly suitable to connect two single fiber FCs for a fast, precisely, quality field connection. The FC adapters feature zirconia ceramic alignment sleeves which provide precision mating for single-mode applications.
2. Optical Cable Adaptor Feature and Benefits:
3. Fiber Optic Adapter Applications:
4. Optic Adapter Specification & Technology Parameters:
| parameter | SC, FC, ST, LC, MU, ST |
| End-face | APC/UPC/PC |
| Mode | Single-mode & multi-mode |
| Sleeve | Zirconia ceramic, phosphor bronze |
| Insertion loss (dB) | ≤0.2 |
| Exchangeability (dB) | ≤0.2 (connect randomly) |
| Tensile strength (dB) | ≤0.2 (0~100N) |
| Vibration (dB) | ≤0.2(5~50Hz, 1.5mm amplitude) |
| Temp. Range (dB) | ≤0.2(-40~80℃, 21 cycles) |
5. Ordering Information:
EX: OFA-D-FC-APC-Z-N-N
| OFA | -X | -XX | -XX | -XX | -X | -X |
|
S: simplex D: duplex |
SC FC ST LC MU ST |
APC UPC PC |
Z: Zirconia ceramic, P: phosphor bronze |
W: with flange N: no flange |
W: with shutter N: no shutter |
|
| Fiber mode | Connector Type | Connector Type | Sleeve | Flange type | Shutter type |
| Parameter | Unit | Value |
| Connector | / | FC ST SC LC |
| Sleeve | / | Zirconia |
| Insertion Loss | dB | ≤0.20(Plug≤0.30) |
| Repeatability | Time | ＞1000 |
6.More Options Optic Adapters:
7. Wuhan Geehe Comm Service:
1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity
2) Compact Structure
Small size, it can be directly installed in a variety of transfer box and just take up little space
3) Strict Quality Control
We guarantee that every product to the hands of customers is subject to stringent testing standards
4) Big Production Capacity
800 Skilled workers and 5 Main production Lines, the optic adapter 8,900 pcs/ Day.
