Product Details:
|
| Model Name: | SC Patch Cable Fiber Optic | Cable Diameter: | 3.0mm |
|---|---|---|---|
| Fiber Counts: | 2 Cores | Polishing: | UPC/APC/PC |
| Jacket Material: | PVC/LSZH/OFNR | Cable Length: | 1M,2M,3M,10M...customize |
| Cable Dimensions: | 3.0mm | Jacket Color: | Orange, Yellow, Aqua... |
| Fiber Type: | Multimode 62.5/125 | Polarity: | Type A To B Crossover (Most Common For Duplex Patch Cords) |
| Highlight: | SC/UPC Fiber Optic Patch Cable,2.0mm Fiber Optic Patch Cord,100 Meters Fiber Optic Patch Cable |
||
2.0mm Singlemode SC/UPC Simplex Fiber Optic Patch Cable 100 Meters
1. Fiber Patch Cord Basic Introduction:
Singlemode and multimode fiber optic patch cables of 9/125 (OS1), 62.5/125 (OM1), and 50/125 (OM2/OM3/OM4), which are engineered to exceed TIA-568 performance requirements. Built with a bend-insensitive fiber design, these patch cables have the ability to support high-speed bandwidth network applications from Gigabit Ethernet (GbE), 10GbE, 40GbE, and to 100GbE. These patch cables are terminated at both ends with a variety of connector types that range from LC, SC, and ST as well as MTP.
2. Fiber Optic Patch Cord SC To SC
3. DuplexSC To SC Patch Cord Application:
4. Specification&Technology Parameters
| Parameters | Value | ||||
| Connector Type | LC/UPC,LC/UPC | ||||
| Center Wavelength(nm) | 1310 or 1550 | ||||
| Max.Insertion Loss(dB) | 0.3 | ||||
| Min.Extinction Ratio(dB) | 23 | ||||
| Min.Return Loss(UPC) (dB) | 55 | ||||
| Min.Return Loss(APC) (dB) | 65 | ||||
| Key Orientation | Slow Axis | ||||
| Axis Alignment(deg) | ±3 | ||||
| Operating Temperature(℃) | -20~+70 | ||||
| Storage Temperature(℃) | -40~+85 | ||||
| FIber Type | PM Panda Fiber, Corning Fiber | ||||
* For Device with connector.IL is 0.3dB higher,RL is 5dB lower,ER is 2dB lower.
* The default connector key is aligned to the slow axis.
5. Fiber patch cord SC Specification& Technology Parameter:
| Parameter | Unit | Index | |||
| End-Face Type | PC | UPC | APC | ||
| IL | dB | SM: ≤0.3；MM ≤0.1 | |||
| Repeatability | dB | ≤0.1 | |||
| interchangeability | dB | ≤0.2 | |||
| RL | SM | dB | ≥50 | ≥50 | ≥50 |
| MM | dB | ≥36(Without APC connector) | |||
| Mating Times | ＞1000 | ||||
| Operating Temperature | ℃ | -40~ +80 | |||
* EX:OFC-D-LA-LA-09-1-1.0
6. Connector Type Abbreviations:
SC - a snap-in style connector. Known for its excellent performance. Referred to as Subscriber Connectors, Square Connectors, or Standard Connectors.
ST - a very popular choice connector for Multimode networks. Also referred to as Straight Tip connectors, they utilize a bayonet-style coupling type, enabling a simple twist-on and twist-off installation.
FC - was at one time the most popular single-mode connector type, but is now typically being replaced by SC and LC connectors. Also known as Ferrule Connectors, they utilize a screw-on coupling type to be used in high-vibration environments and are commonly used for datacom, telecom, measurement equipment, and single-mode lasers.
LC - a small form factor connector—measuring half the size of an SC connector. This is a popular choice for single-mode cables. Also referred to as Lucent Connectors, Little Connectors, or Local Connectors, these snap-in connectors are typically used for high-density connections and are compatible with plug-and-play devices such as SFP modules and XFP transceivers.
7. Geehe Factory Service:
1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity
2) Compact Structure
Small size, it can be directly installed in a variety of transfer box and just take up little space
3) Strict Quality Control
We guarantee that every product to the hands of customers is subject to stringent testing standards
4) Factory Audit
We cooperate with famous brands and Japanese customers, with 15 years of factory inspection experience and be familiar with the whole inspection process by SGS
5) Own Testing Labs
Our factory has its own Agin testing Labs, the machines imported from Japan, the reliability can be guaranteed
