2U Rack Mount MPO To LC 288 Core HD Patch Panel

2U Rack Mount MPO To LC 288 Core HD Patch Panel
2U Rack Mount MPO To LC 288 Core HD Patch Panel 2U Rack Mount MPO To LC 288 Core HD Patch Panel 2U Rack Mount MPO To LC 288 Core HD Patch Panel

Large Image :  2U Rack Mount MPO To LC 288 Core HD Patch Panel

Product Details:
Place of Origin: Hubei,China
Brand Name: Geehe Comm
Certification: ISO9001:2015,ISO14001:2015,RoHS
Model Number: GH-HD-Cassette-008
Payment & Shipping Terms:
Minimum Order Quantity: 600 pcs
Price: Negotiation
Packaging Details: Inside box for each Cassette with Pressure defense packaging,thicker outer carton
Delivery Time: Within 5-7 working days after confirm order
Payment Terms: T/T, L/C, D/A,Ali Pay,Cash
Supply Ability: 400 Pcs/ Day

2U Rack Mount MPO To LC 288 Core HD Patch Panel

Description
Model Name: 288 Fiber Optic Patch Panel Material: Cold-rolled Steel Sheet
Cassettes: MPO Cassettes Max Capacity: 288 Cores
Fiber Type: Single Mode,Multimode OM2,OM3,OM4,OM5 Enclosure Body: SPCC,Black Powder Coated
Patch Cord Quantity: 1x24Fo, 2x12Fo ,1x12 Fo Color: Aqua And Black
Module Qty: 3 Slots 4 Slots 5 Slots 12 Slots Dimension: 483 X 375 X 2HU (mm)
Highlight:

2U 288 core HD Patch Panel

,

288 core mpo to lc patch panel

,

288 core Rack Mount patch panel

 High Density 2U Rack Mount MPO-LC Module 288 Fiber Optic Patch Panel



1. Product Description:



High-Density Fiber Cassette solution that supports up to High-Density Fiber Cassettes, maximizing rack space and allowing for up to 144 Duplex LC Ports (288 fiber connections) in just 2U of space.



The Installation is simple, with the cassettes being easily installed or removed using push / pull tabs to lock or unlock them from the panel; no tools required.



Management is a breeze with an optional rear-mounting cable management bracket that allows you to rout your cabling neatly and safely. A fold-down door panel is featured on the front of the unit and protects your connections while rotating out of the way to provide full access. The door panel can also be removed altogether for installations where constant access is preferred. Constructed of heavy-duty steel housing.





2. Features & Benefits:



  • Compact design for space-saving
  • Sliding drawer for an easy front and inside
  • High-Density Fiber Enclosure Panel, 2U 14-Cassette
  • 8 MTP Elite (24 Fiber) Connectors in Rear for Core Connection
  • Available with 12 Fiber MTP (10/40G) OR 24 Fiber MTP (100G) Connectors
  • The module box can be installed or removed from the front or rear of the distribution frame
  • 3* 16F module or 3*6-port adapter panels in each layer

2U Rack Mount MPO To LC 288 Core HD Patch Panel 0



3. HD Fiber Patch Panel Applications:



  • Storage area networking fiber channel
  • High-density architectures
  • Data communication network
  • Optical System Access network

2U Rack Mount MPO To LC 288 Core HD Patch Panel 1





4. Specification and Technology Parameter



Product HD 2U Fiber patch panel
Material Cold-rolled steel sheet
Cassettes 4 pcs MPO Cassettes
Max Capacity 288 Cores
Adapter LC adapter, MPO adapters
Colors Black
Patch cord Qty 1x24fo, 2x12Fo ,1x12 Fo
Fiber Mode G657A1, OM1,Om2,Om3,Om4
Panel Height 2U





5. HD Optic Patch Panel More Types:



2U Rack Mount MPO To LC 288 Core HD Patch Panel 2





6. Frequent Q&A For HD Fiber Patch Panel:



Q: What are the benefits of using a patch panel?
A: Patch panels will allow testing routing and maintenance of network cables connected to your network. With a patch panel, this is quickly done just by making changes to cables on the patch panel itself. Patch panels also allow for easier cable management and identification of cable routing.


Q: What is a rack unit?
A: A rack unit U or RU is a unit of measure that describes the height of equipment designed to mount in a rack. A rack unit is 1.75 inches. Typically one rack unit will take three vertical screw holes on each side of a standard rack.



Q: Can I use any fiber patch cable in my network with my enclosure?

A: If your fiber enclosure is loaded you must have cables that are compatible with the included adapters. For unloaded enclosures, you must select adapter panels that correspond to your fiber connector type or use a splice tray for single- and mass-fusing.


Q: What are the differences between the fiber connectors?


ST- Uses a push and turn to lock system


SC- Has a molded plug casing with push and pull locking system



7. Geehe Comm Service :

  • Optical performance 100% factory tested
  • UPC, and APC polish types are available for connectorized products
  • Low Insertion Loss, Back Reflection and PDL
  • High-level OEM Service
  • Payment SupportFree Samples for testing
  • Factory Audit by the third party (SGS)

2U Rack Mount MPO To LC 288 Core HD Patch Panel 32U Rack Mount MPO To LC 288 Core HD Patch Panel 4
