Product Details:
|
| Model Name: | Patch Panel For Fiber Optic Cables | Material: | Cold-rolled Steel Sheet |
|---|---|---|---|
| Cassettes: | MPO Cassettes | Max Capacity: | 144 Cores |
| Adapter: | LC Adapter, MPO Adapters | Colors: | Black |
| Patch Cord Quantity: | 1x24fo, 2x12Fo ,1x12 Fo | Panal Height: | 1U,483 X 375x 1HU (mm) |
| Module Qty: | 3 Slots 4 Slots 5 Slots 12 Slots | Application: | 10G 40G 100G Data Center |
| Highlight: | 144 Cores MPO Cassettes Patch Panel,Pre terminated MPO Cassettes Patch Panel,1U MPO Cassettes Patch Panel |
||
Pre-terminated 144 Fiber HD Cassette Patch Panel For Fiber Optic Cables
1. Product Description:
1RU HD Fiber Optic Panels allow a mix-and-match of HD fiber and copper snap-in cassettes. Cassettes quickly snap in and pull out of the panel, making installation and changes easier than ever. Alignment tabs on the rear of the panel ensure cassettes are inserted correctly.
With this High-Density Fiber Patch Panel, you can easily make one rack unit support your 10GB or higher applications. They allow you to quickly add new devices to your system without having to manually install or reconfigure other devices. The fiber is routed and connected on the inside of the cassette. There is no cutting, polishing, or terminating.
2. HD Fiber Patch Panel Features & Benefits:
Available with OM4 or single-mode fiber arrays and adapters
Also available with standard or low loss (Elite) ferrule MTP connectors
Connect together with high-density female MTP cable assemblies as an interconnection network
Significantly reduce installation time and labor by eliminating field connector terminations
Constructed of lightweight yet durable rolled steel our loaded cassette weighs less than 5 pounds
Pre-terminated High Density 144 Fiber HD Cassette
Mounts on standard 19" racks or cabinets
3. HD Patch Panel Application:
Storage area networking fiber channel
High density architectures
Data communication network
Optical System Access network
4. Specification and Technology Parameters :
| Product | HD 1U Fiber patch panel |
| Material | Cold-rolled steel sheet |
| Cassettes | 4 pcs MPO Cassettes |
| Max Capacity | 96 Cores |
| Adapter | LC adapter, MPO adapters |
| Colors | Black |
| patch cord Qty | 1x24fo, 2x12Fo ,1x12 Fo |
| Fiber Mode | G657A1, OM1,Om2,Om3,Om4 |
| Panel Height | 1U |
5. Frequent Q&A For HD Fiber Patch Panel:
Q: What are the benefits of using a patch panel?
A: Patch panels will allow testing routing and maintenance of network cables connected to your network. With a patch panel this is quickly done just by making changes to cables on the patch panel itself. Patch panels also allow for easier cable management and identification of cable routing.
Q: What is a rack unit?
A: A rack unit U or RU is a unit of measure that describes the height of equipment designed to mount in a rack. A rack unit is 1.75 inches. Typically one rack unit will take three vertical screw holes on each side of a standard rack.
Q: Can I use any fiber patch cable in my network with my enclosure?
A: If your fiber enclosure is loaded you must have cables that are compatible with the included adapters. For unloaded enclosures, you must select adapter panels that correspond to your fiber connector type or use a splice tray for single- and mass-fusing.
Q: What are the differences between the fiber connectors?
ST- Uses a push and turn to lock system
SC- Has a molded plug casing with push and pull locking system
6. More HD Fiber Optic Patch Panel Options:
