Single Mode FTTH 1.2mm LC UPC Fiber Connector

Large Image : Single Mode FTTH 1.2mm LC UPC Fiber Connector

Product Details:

Place of Origin:	Hubei,China
Brand Name:	Geehe Comm
Certification:	UL,ISO9001, RoSH, CE
Model Number:	GH-LC-002

Payment & Shipping Terms:

Minimum Order Quantity:	500 pcs
Price:	Negotiation
Packaging Details:	Plastic box per pc with Pressure defense sponge, outer carton
Delivery Time:	Within 3-5 working days
Payment Terms:	T/T, D/P, D/A, Western Union, MoneyGram,LC
Supply Ability:	8,900 pcs per day

Contact Now

Single Mode FTTH 1.2mm LC UPC Fiber Connector

Description

Model Name:	Quick LC Fiber Optic Connectors	Connector Type:	SC/FC/LC/ST/MTRJ/MU/MPO Ect
Ferrule End-face:	PC,UPC,APC	Fiber Type:	Singlemode, Multimode
Color:	Blue,Green,Grey,Aqua,Purple Etc	Cable Applicable:	3.1 X 2.0 Mm Drop Cable
Installation Time:	Within 60s ( No Fiber Cut )	Sleeve:	Caremic/Phosphor Bronze
Highlight:	1.2mm LC UPC Fiber Connector , 1.2mm ftth fast connector , 1.2mm single mode fiber connectors

Basic Structure Single-Mode LC UPC Fiber Optic Connectors For FTTH

Brief Introduction:

LC/UPC Fiber Optic Connector is an important component used in a fiber-optic network. It is also the key part used in fiber optic patch cords and fiber optic pigtails.

Geshe manufactures various types of fiber optic connectors, including both standard and non-standard types.

Single-mode fiber optic connectors are with PC, UPC, or APC polish, while Multimode fiber optic connectors are only with PC or UPC polish.

Single Mode FTTH 1.2mm LC UPC Fiber Connector 0

Fiber Optic connectors Features and Advantages:

Pull-proof design prevents signal interruption
Teflon tube in rear of connector ensures clean epoxy injection
Available with 0.9mm, 1.2mm, 2.0mm, 3.0mm, flex, and 45°/90° boots in multiple colors
Free-floating ceramic ferrule
Boots in a variety of colors
Telcordia style boots
Clips are available for SC and LC duplex connectors
Good exchangeability and good durability

Single Mode FTTH 1.2mm LC UPC Fiber Connector 1

Application of LC Connector:

Telecommunication networks
Local area networks
Data processing networks
LAN, WAN, SAN and FTTx application
Fiber Sensor
Test Instrumentations

Single Mode FTTH 1.2mm LC UPC Fiber Connector 2
Technology Specification& Parameters:

Parameter		Unit	Index
End-Face Type			PC	UPC	APC
IL		dB	SM: ≤0.3; MM ≤0.1
Repeatability		dB	≤0.1
Interchangeability		dB	≤0.2
RL	SM	dB	≥50	≥50	≥50
	MM	dB	≥36(Exclusive APC Connector)
Mating Times			＞1000
Operating Temperature		℃	-40~ +80

Order Information:

OFC	-X	-XX	-XX	-XX	-X	-X
	S: Simplex D: Duplex	LA:LC/APC LC:LC/UPC LP:LC/PC	LA:LC/APC LC:LC/UPC LP:LC/PC	09:0.9mm 20:2.0mm 30:3.0mm	0:G652D 1:G657A 2:50/125 3:62.5/125 4:others	0.5:0.5m 1.0:1.5m 10:10.0m
	Fiber Mode	Connector Type	Connector Type	Cable Diameter	Fiber Type	Fiber Length

More LC Connectors:

Geehe Factory Service:

Continuous improvement; accepting new challenges
Innovating new processes, and creating new products for the benefit of our customers
Consultative service and strive to ensure a positive and productive experience
Efficient use of all transportation modes and transit times
Greater visibility and real-time information

Single Mode FTTH 1.2mm LC UPC Fiber Connector 4
