Product Details:
|
| Model Name: | E2000/APC Fiber Optic Connector Kit | Connector Type: | SC/FC/LC/ST/MTRJ/MU/MPO Ect |
|---|---|---|---|
| Ferrule End-face: | PC,UPC,APC | Fiber Type: | Singlemode, Multimode |
| Color: | Blue,Green,Grey,Aqua,Purple Etc | Cable Applicable: | 3.1 X 2.0 Mm Drop Cable |
| Installation Time: | Within 60s ( No Fiber Cut ) | Sleeve: | Caremic/Phosphor Bronze |
| Housing: | Blue 9/125 Singlemode | Fiber Cable: | 0.9mm,2.0mm,3.0mm |
| Highlight: | E2000/APC Fiber Optic Connector,2.0mm Fiber Optic Connector,2.0mm E2000 apc fiber connector |
||
E2000/APC Fiber Optic Connector Kit for 2.0mm Single Mode Fiber Cable
Brief Introduction:
E2000 fiber optic connectors and related products include both single-mode and multimode types. There are single-mode E2000 UPC connectors, single-mode E2000 APC connectors, and multimode E2000 UPC connectors, and there are adapters to use with them accordingly. E2000 products include simplex and duplex versions.
E-2000 is a high-performance connector that meets the highest standards by excellence in design and manufacturing processes. Only high-quality and high-precision materials are used to guarantee connections at the highest level. HUBER+SUHNER E-2000 products meet the international standards IEC 61754-15 and TIA 604-16 and are naturally RoHS/REACH compliant.
E2000 Connectors Fiber Optic connectors Features and Advantages:
• Automatic metal shutter in connector and adapter for dust protection and laser safety
• One-piece connector design for easy termination
• Colour coding of connector and adapter
• Mechanical coding of connector and adapter
• Ideal for high-power applications
• Switchable duplex clips
Notes for Fiber Optic Connector Installation:
Besides different installation methods for different connector types, several things need to be paid attention to when installing fiber optic connectors, especially when a fiber patch cord has two different types of connectors, such as LC-SC fiber optic patch cord or FC-ST fiber optic patch cord.
The bared fiber must be thoroughly cleaned with fiber optic cleaning fluid. Never clean the fiber with dry tissue. Before the connection is made, the end of each fiber must have a smooth finish that is free of defects such as hackles, lips, and fractures.
The cable should be cut about one inch longer than the required finished length.
Be sure to use strippers made specifically for use with fiber rather than metal wire strippers because damage can occur and then weaken the fiber.
Application of E2000 Connector:
Technology Specification& Parameters:
| Parameter | Unit | Index | |||
| End-Face Type | PC | UPC | APC | ||
| IL | dB | SM: ≤0.3； MM ≤0.1 | |||
| Repeatability | dB | ≤0.1 | |||
| Interchangeability | dB | ≤0.2 | |||
| RL | SM | dB | ≥50 | ≥55 | ≥65 |
| MM | dB | ≥36(Exclusive APC Connector) | |||
| Mating Times | ＞1000 | ||||
| Operating Temperature | ℃ | -40~ +80 | |||
More Fibre Optic Connector Types:
