Product Details:
|
| Model Name: | LC Fiber Optic Connector | Connector Type: | SC/FC/LC/ST/MTRJ/MU/MPO Ect |
|---|---|---|---|
| Ferrule End-face: | PC,UPC,APC | Fiber Type: | Singlemode, Multimode |
| Color: | Blue,Green,Grey,Aqua,Purple Etc | Cable Applicable: | 3.1 X 2.0 Mm Drop Cable |
| Installation Time: | Within 60s ( No Fiber Cut ) | Sleeve: | Caremic/Phosphor Bronze |
| Housing: | Blue 9/125 Singlemode | Fiber Cable: | 0.9mm,2.0mm,3.0mm |
| Highlight: | 09MM LC Fiber Optic Connector,FTTH 09MM Fiber Optic Connector,09MM single mode fiber connectors |
||
Smaller Size Single Mode 09MM LC Fiber Optic Connector for FTTH
Brief Introduction:
A fiber optic connector terminates the end of a fiber optic cable and enables quicker connection and disconnection than splicing. It has to be aligned properly to the microscopic glass fibers completely in order to allocate for communication. In all, there are nearly 100 fiber optic connectors in the market, but only a few represent the majority of the market — LC connector, SC connector, ST connector, FC connector, etc. Next, some detailed information about the above connectors will present to you.
LC refers to Lucent Connector. It is a push-pull, small form factor connector that uses a 1.25mm ferrule, half the size of the SC. LC, due to the combination of small size and latch feature, is ideal for high-density connections.
Fiber Optic connectors Features and Advantages:
Notes for Fiber Optic Connector Installation:
Besides different installation methods for different connector types, several things need to be paid attention to when installing fiber optic connectors, especially when a fiber patch cord has two different types of connectors, such as LC-SC fiber optic patch cord or FC-ST fiber optic patch cord.
The bared fiber must be thoroughly cleaned with fiber optic cleaning fluid. Never clean the fiber with dry tissue. Before the connection is made, the end of each fiber must have a smooth finish that is free of defects such as hackles, lips, and fractures.
The cable should be cut about one inch longer than the required finished length.
Be sure to use strippers made specifically for use with fiber rather than metal wire strippers because damage can occur and then weaken the fiber.
Application of SC Connector:
Technology Specification& Parameters:
| Parameter | Unit | Index | |||
| End-Face Type | PC | UPC | APC | ||
| IL | dB | SM: ≤0.3；MM ≤0.1 | |||
| Repeatability | dB | ≤0.1 | |||
| Interchangeability | dB | ≤0.2 | |||
| RL | SM | dB | ≥50 | ≥55 | ≥65 |
| MM | dB | ≥36(Exclusive APC Connector) | |||
| Mating Times | ＞1000 | ||||
| Operating Temperature | ℃ | -40~ +80 | |||
Order Information:
| OFC | -X | -XX | -XX | -XX | -X | -X |
| S: Simplex D: Duplex |
LA:LC/APC LC:LC/UPC LP:LC/PC | LA:SC/APC LC:SC/UPC LP:SC/PC | 09:0.9mm 20:2.0mm 30:3.0mm | 0:G652D 1:G657A 2:50/125 3:62.5/125 4:others | 0.5:0.5m 1.0:1.5m 10:10.0m |
|
| Fiber Mode | Connector Type | Connector Type | Cable Diameter | Fiber Type | Fiber Length |
More Fibre Optic Connector Types:
Geehe Comm Service:
