Product Details:
|
| Model Name: | FC APC Fiber Optic Connectors | Connector Type: | SC/FC/LC/ST/MTRJ/MU/MPO Ect |
|---|---|---|---|
| Ferrule End-face: | PC,UPC,APC | Fiber Type: | Singlemode, Multimode |
| Color: | Blue,Green,Grey,Aqua,Purple Etc | Cable Applicable: | 3.1 X 2.0 Mm Drop Cable |
| Installation Time: | Within 60s ( No Fiber Cut ) | Sleeve: | Caremic/Phosphor Bronze |
| Highlight: | 3.0mm FC APC Fiber Optic Connectors,High Capacity Fiber Optic Connectors |
||
High Capacity 3.0mm Pre-Polished Green Color FC APC Fiber Optic Connectors
Brief Introduction :
The FC connector is a fiber-optic connector with a threaded body, which was designed for use in high-vibration environments.
It is commonly used with both single-mode optical fiber and polarization-maintaining optical fiber.
FC is similar in appearance to ST however the outer ring provides a threaded screw-on connection. FC stands for "fixed-contact".
These connectors are suitable for use in test equipment or equipment that may be mobile or not stationary.
They are becoming less common, displaced by SC and LC connectors. The FC connector has been standardized in TIA fiber optic connector interpretability standard EIA/TIA-604-4.
Geehe's optic connectors with 850,000 pcs/ month, all the raw materials with big quantity storage for customers, widely used for fiber patch cords and attenuators, etc.
Fiber Optic connectors Features and Advantages:
Application of ST Connector :
Technology Specification& Parameters:
| Parameter | Unit | Index | |||
| End-Face Type | PC | UPC | APC | ||
| IL | dB | SM: ≤0.3；MM ≤0.1 | |||
| Repeatability | dB | ≤0.1 | |||
| Interchangeability | dB | ≤0.2 | |||
| RL | SM | dB | ≥50 | ≥55 | ≥60 |
| MM | dB | ≥36(Exclusive APC Connector) | |||
| Mating Times | ＞1000 | ||||
| Operating Temperature | ℃ | -40~ +80 | |||
Order Information:
| OFC | -X | -XX | -XX | -XX | -X | -X |
| S: Simplex D: Duplex |
SA:ST/APC SC:ST/UPC SP:ST/PC | SA:ST/APC SC:ST/UPC SP:ST/PC | 09:0.9mm 20:2.0mm 30:3.0mm | 0:G652D 1:G657A 2:50/125 3:62.5/125 4:others | 0.5:0.5m 1.0:1.5m 10:10.0m |
|
| Fiber Mode | Connector Type | Connector Type | Cable Diameter | Fiber Type | Fiber Length |
