Product Details:
|
| Model Name:: | Fiber Pigtail Connector | Connector: | LC/APC Connectors |
|---|---|---|---|
| Fiber Count: | 12 Fiber | Cable Mode: | Single-mode Communication |
| Cable Color: | Yellow | Cable Type: | OS2 Standard |
| Core Do: | 9/125μm Core Diameter | Jacketing: | OFNR (Riser) Rated |
| End-face Type: | PC,UPC,APC | Fiber Length: | 1-500M |
| Highlight: | 9/125μm Fiber Optic Pigtail,OS2 Standard Fiber Optic Pigtail,9/125μm lc apc pigtail |
||
Low Insertion Loss 12 Stand Fiber Pigtail Single Mode 9/125 LC APC Connectors
Brief Introduction:
Single-mode (OS2) 12 Strand Fiber Pigtail. LC/APC 9/125um (Yellow) Fiber Pigtail for 10G/100G fiber links.
Manufactured using OS2 fiber, standard jacket Fiber Pigtail is designed for light to medium-duty indoor applications such as data-center racks and desktop/network connections. Custom configurations available.
12 Cores Fiber pigtail cables provide a fast way to make factory terminations in the field. Factory terminated pigtails can easily be fusion or mechanically spliced to an existing fiber line. Each fiber strand in the kit has a color-coded buffer for easy identification and the colors are industry standard.
Benefit&Features of Fiber Pigtail Connector:
-- Low insertion loss and back reflection loss
-- Good exchangeability
-- High-temperature stability
-- LSZH sheath (low smoke zero halogens)
-- Each packaging unit includes a test chart for each fiber
-- 900μ fibers in red, green, blue, yellow, white, gray, brown, purple, turquoise, black, orange, pink
-- 100% inspected for optical characteristics before shipment
-- Boots in a variety of colors
Applications of LC/APC Single Mode Pigtails:
-- Optical fiber access networks
-- Optical fiber CATV
-- Optical fiber test equipment
Specification &Technology Parameters:
| Item | SM (Single-Mode) | MM (Multimode) | |||
| Fiber Cable Type | G625D/G655/G6571A/G657A2 | OM1 | OM2/OM3/OM4 | ||
| Fiber Diameter (um) | 9/125 | 62.5/125 | 50/125 | ||
| IL(dB) | ≤0.3 | ≤0.1 | |||
| Cable Type | Simplex, Duplex, Fan-Out | ||||
| Connector Type | LC, SC, FC, ST, MU, MPO, MTRJ, D4, DIN, SMA, FDDI, ESCON etc. |
||||
| Cable OD (um) | 0.9/1.6/1.8/2.0/2.4/2.8/3.0 | ||||
| End-face Type | PC | upc | APC | UPC | UPC |
| Retun Loss(dB) | >45 | >50 | >60 | / | |
| Insert-pull Test (dB) | <0.2 | <0.3 | <0.15 | ||
| Interchangeability (dB) | <0.1 | <0.15 | <0.1 | ||
| Mating Times | >1000 | ||||
| Anti-tensile Force (N) | >70 | ||||
| Temperature Range (℃) | -40~+80 | ||||
LC/APC Single Pigtails Specification:
| Parameter | Unit | Index | |||
| End-Face Type | PC | UPC | APC | ||
| IL | dB | SM: ≤0.3；MM ≤0.1 | |||
| Repeatability | dB | ≤0.1 | |||
| Interchangeability | dB | ≤0.2 | |||
| RL | SM | dB | ≥45 | ≥50 | ≥60 |
| MM | dB | ≥36(Exclusive APC Connector ) | |||
| Mating Times | ＞1000 | ||||
| Operating Temperature | ℃ | -40~ +80 | |||
Ordering Information:
| OFC | -X | -XX | -XX | -XX | -XX | -XX |
| S: Simplex D: Duplex | LA:LC/APC LC:LC/UPC LP:LC/PC | LA:LC/APC LC:LC/UPC LP:LC/PC | 09:0.9mm 20:2.0mm 30:3.0mm | 0:G652D 1:G657A 2:50/125 3:62.5/125 4:others | 0.5:0.5m 1.0:1.5m 10:10.0m |
|
| Fiber Mode | Connector Type | Connector Type | Cable Diameter | Fiber Type | Fiber Length |
Fiber Optic Pigtails Packaging:
